Metal Powder Water Atomization Pump - 130 Bar to 500 Bar - EMB
| MODEL-SPM | FLOW RATE | PRESSURE | MOTOR POWER | SELECT | ||||
|---|---|---|---|---|---|---|---|---|
| l/min | Gpm | bar | psi | Mpa | hp | KW | ||
| EMB 32 - 670 | 113 | 30.1 | 300 | 4351 | 30 | 100 | 75 |
|
Note: Required diesel engine HP will be 20% more than motor HP.
-
Drier TypeElectric Motor Driven, Diesel Engine Driven, PTO driven
-
Power Supply3 Phase
-
Liquid End MaterialStainless Steel
-
Inlet Connection2” BSPF
-
Outlet Connection1” BSPF
-
Inlet PressureFlooded to 2 Bar
-
Working Fluid Temp.60 °C
-
Bare Pump Weight374 Kg.
-
Bare Pump Size748 X 610 X 323 mm
-
Oil Capacity8 Ltr.
-
Oil GradeGear Oil 220
S-20 Safety Valve
- Ensures maximum safety by releasing excess pressure automatically.
- Compact S-20 Safety Valve built for reliability and long life.
T 60 Pressure Regulating Valve
- Delivers precise pressure regulation for large high-flow pump systems
- Heavy-duty T-60 PRV designed for maximum industrial performance.
Pulsation Dampener
- Reduces pressure fluctuations and vibration caused by reciprocating plunger pumps.
- Enhances system stability, nozzle performance, and pump life by ensuring steady discharge flow.
Sand Filter
- 80–100 micron precision sand filtration for fine particle and scale removal.
- Extends pump, nozzle, and valve life by preventing contamination and abrasion.
Basket Filter
- High-accuracy pressure gauge for continuous monitoring up to 1500 BAR.
- Built with stainless steel casing and glycerin-filled design to resist vibration and corrosion.
